Place of Origin
Guangdong, China
Model Number
IP500-12-Plus
Input Voltage
10.8 ~ 16.0VDC
Output Voltage
220VAC (±3%); 230VAC (-6%~+3%); 240VAC (-9%~+3%)
Output Frequency
50/60Hz ± 0.2%
Size
286*163.5*78mm (with decorative cover)
Continuous output power
500W@35℃@ Rated input voltage
Output wave
Pure Sine Wave
RS485 com. port
5VDC/200mA
Environment temperature
-20℃ ~ +60℃ (Refer to the Derating Curve)
Safety
EN/IEC62109-1,UL1741,UL458,C SA C22.2#107.1
